Top 10 aeroaces.com Competitors

vintagemodelplans.com

Printed Plans and Article NOT a KIT or MODEL no material Have a crack at an all metal 24 pdr. Gun with Cast Iron Carriage Full size plan on a sheet 17” x 11” Two page article with photos Note: no measurements use ruler or scale on plan Scale 1:16 Length 8” Width 3 1/5” As drawn and described by I. R. Stair This gun should delight the model engineer who likes to produce something ornamental occasionally, as the whole model can be made in metal. Those without facilities for working in metal can take comfort in the fact that a dull black finish is most appropriate and therefore other materials can be used to produce a realistic model. The gun is a straightforward job and I do not think there is much purpose in describing the construction in full as it would merely repeat my previous articles in Model Maker. The feature which differs most from the other model guns is the carriage cheeks or sides. If metal is not used the best alternative is Perspex; avoid ply­wood owing to the trouble of cleaning up the edges for a good finish. Marking out has to be carefully done and holes drilled in the corner of each opening and in the internal angles of the outline. I found an Abrafile about the best tool for cutting in between the holes for if it is used with care, very little cleaning up is required. . All other parts are quite simple to make in metal, plastic or timber, the shapes being quite clear from the drawing.. THE subject of the accompanying drawing is a 24 pdr. ship's gun mounted on a cast iron carriage. These guns were used in naval shore establishments for coastal defence and in the trade castles in Africa and Asia. I can find no evidence of their use in ships. It .is interesting to see how the general form of the wooden carriage was followed closely in cast iron, the designers not being able to think basically enough to produce a shape more appropriate to the material used. This happened in thee distant past when early stone buildings followed the form o

horailroading.net

information and discussion on all aspects of ho scale model railroads
